Product Details:
Payment & Shipping Terms:
|
| Material: | Red Color Painted |
|---|
Technical Parameters of the Electric pallet stacker’s CDD-20:
| Rated lifting weight | 2000kg |
| Load center distance | 500mm |
| Dynamic way | battery |
| Driving way | Stand up |
| The wheelbase | 1480mm |
| Tire type | Polyurethane wheel |
| Number of wheels (front/rear) | 1x+2/4 |
| Before the wheel track | 510 |
| After the wheel track | 620 |
| Height of door frame | 2080mm |
| Maximum lifting height | 3000mm |
| Maximum height during operation | 3380mm |
| The goods fork length | 1000mm |
| Body length | 1870mm |
| Body width | 860mm |
| Turning radius | 1800mm |
| Minimum ground clearance | 35mm |
| The whole weight of | 950kg |
| Drive motor | 1.2KW |
| The oil pump motor | 2.2KW |
| Drive motor control mode | AC |
| Oil pump motor control mode | AC |
| Turned to the way | Hydraulic booster |
