| Color: | Red Painted |
|---|
| Rated lifting weight | 1000kg |
| Load center distance | 500mm |
| Battery | Lead acid battery 70ah*5 |
| Driving way | Car type |
| The wheelbase | 1430mm |
| Tire type | Elastic solid tire |
| Number of wheels (front/rear) | 2/2 |
|
Before the wheel track
|
1050mm |
| After the wheel track | 950mm |
| Height of door frame when retracting | 2150mm |
| Maximum lifting height | 3000mm |
| Maximum height during operation | 4050mm |
| Height of roof guard | 2020mm |
| The goods fork length | 1070mm |
| Body length (excluding fork) | 1800mm |
| Body width | 1150mm |
|
Turning radius
|
1900mm |
| Minimum ground clearance | 150mm |
| The whole weight of | 1500kg |
| Drive motor | 2.5KW |
| The oil pump motor | 1.5KW |
| Drive motor control mode | AC |
| Oil pump motor control mode | AC |
| Turned to the way | Hydraulic booster |
